Features:

◆ Using pliers to pick up the paper, it can ensure high-speed safety.

◆ The special feeder design can feed the paper correctly, and the feeder deceleration unit has two functions: normal and deceleration, which can be switched arbitrarily.

◆ The side positioning adopts a push-pull device, which is easy to switch and can be selected according to different paper types.

◆ Detection of double-sheet feeding and front positioning, side positioning, abnormal feeding, automatic shutdown device.

◆ Pneumatic locking system for die cut frame.

◆ Die cutting pressure can be adjusted according to paper quality, up to 300 tons.

◆ The upper and lower needling devices of the waste removal section is simple and easy, and it is equipped with the secondary cleaning and removing the waste paper edge.

◆ The feeder and stacker are equipped with non-stop devices to ensure uninterrupted production.

◆ Touch screen display system, including computerized automatic detection device, provides operation instructions for each part and abnormal elimination instructions.

◆ Wide range of die cutting capacity from 80g to within 4mm of corrugated paper.

◆ The all-in-one machine is hoisted, the height of the whole machine is increased by 300mm, and the pile of paper is increased by 25%.

◆ Max stamping pressure up to 600 tons, which makes it able to achieve better 3D and exquisite effect on large format printing materials such as wine boxes and cigarette boxes.

Feeder:

The design of the stacking preparation table has been improved. The preparation trolley can beused to pre-stack the paper, or the pallet truck can be used to directly send the stacked paper tothe main stacking table.

Adopt powerful four-suction and four-feed high-speed feeder, with stable and smooth paperfeeding.

The high and low angles of the first suction and the second suction can be adjusted separately toadapt to the warping of different paper surfaces.

Imported patented spiral blowing device makes the paper deliver smoothly.

Feeder double-beam type ensures stable and durable paper feeding.

Delivery:

Adopt Taiwan original pull and push dual-use side sheet registration system, which can be easilyselected according to different material.

The paper feeding belt is lengthened to ensure that the corrugated paper is fed smoothly and inplace.

Unigue dual-purpose mechanism for thick and thin paper, which can be switched according todifferent paper, ensuring smooth conveying and positioning of thick and thin paper..

The paper feed roller quick adjustment mechanism is equipped with a weight balance device tofacilitate the adjustment and positioning of the paper more conveniently.

Die cutting:

Pneumatic locking system for die frame, is corvenient and quick.

The two contact points of the front positioning paper stopper can be individually fine-tuned toadapt to precise positioning under different paper conditions.

Using advanced technology, the positioning of a single gripper can be fine-tuned before andafter compensation to meet the requirements of processing accuracy.

Electric eye monitoring throughout the work, with large-capacity man-machine interface LCDdisplay, providing detailed troubleshooting methods.

Equipped with an air-cooled circulating oil temperature cooling system to avoid the movement ofthe creasing strips on the bottom plate due to excessive oil temperature in the machine.

Imported hard die-cut steel plate, which is durable and not easy to deform.

Stritting:

Triple coordinated waste stripping device, precise and powerful, can effectively remove all kindsof shaped wastes.

Double-layer drawer type upper and lower waste removal molds can be quickly adjusted andchangeover.

The upper frame adopts electric control lifting device.

Various specifications of waste removal components are included, which can be combinedarbitrarily according to the die-cutting products, and the changeover is convenient and fast

Hot  stamping:

Max stamping pressure up to 600 tons, which makes it able to achieve better 3D and exquisiteeffect on large fomat printing materials such as wine boxes and cigarette boxes.

Heating base with 20 heating zone each temperature adjustable individually for eficient and accuratetemperature oontrol.

Piling  and  stacking :

The Piling and stacking is equipped with an alarm system: it will stop when a person is detectedto come inside this part.

Equipped with insert counter (optional).

The gripper transmission chain has a tension buffer device.

When the main stacker is full of paper during operation, the non-stop system that automaticallycollect and stack in the secondary stacker, cooperates with the brush pressing, air blowing bufferand left and right patting mechanism to ensure more tidy stacking.

Overview:

High-performance double beam paper feeder

The wacuum pump is Sino-German Baker.

Pneumatic clutch is italian brand, paper feeding electromagnetic clutch is imported from Germany brand.

The main chain of the gripper drive is a special specification imported from Germany lves/lWlS.

The transmission chain of the mechanism is mainly imported from japan.

High-torque transmission belts are mainly imported from Germany.

The bearings matched with the mechanism parts are mainly imported from japan and Europe.

Precision mechanical parts such as high-standard transmission gears and inear cams are imported and assembled from Taiwan.

The whole group of high-precision locators are imported and assembled from Taiwan.

The whole machine's high-quality plastic steel rails, imported and assembled from japan.

The main machine inverter is imported from Yaskawa,apanese.

The PLc controller is imported from Taiwan Yonghong.

Photoelectric switches are mainly japan and Europe brands.

The touch screen for display monitoring and management is 15-inch Kunlun Tongtai.

The whole set of torque limiters are imported from Taiwan.

Safety control of automatic oil feeder, solenoid valve, etc. are imported from Taiwan.
